Categories: Ubiquiti Access Points, Access Points and Bridges, Ubiquiti Networks

Ubiquiti Device Bridge – UDB

Name: Ubiquiti Device Bridge – Wireless Bridging PoE Adapter
SKU: UBI-UDB
Price: 128.00 USD
Availability: InStock

Original price was: $159.00.Current price is: $128.00.

Weight: 1.1 lbs
Dimensions: 7.30 × 4.70 × 2.60 in
Brand: Ubiquiti
Frequency Band: 5 Ghz
Mounting Options/Type: Desk, Mounted, Wall Plate
Shipping & Tax: Calculated at Checkout

1 in stock

Sold: 0

Available: 1

About This Item:

(1) GbE LAN port that provides up to 15W of PoE
5 GHz band with up to 867 Mbps throughput rate
Compatible with
- UniFi Protect PoE cameras
- Talk phones
- Various IoT devices via an Ethernet connection

Have A Question?

888.996.9609 Ask An Expert >

Industry Best Pricing
Quantity discounts available

Friendly Associates
Pre-sales product and solution advice

Expert Tech Support
Add-on tech support plans available

Super Fast Delivery
Same day shipping on most orders

Ubiquiti Device Bridge (UDB) is a high-speed Wi-Fi 5 PoE adapter built for seamless wireless bridging in professional network environments. Operating on the 5 GHz band, it uses advanced MIMO technology and Gigabit Ethernet to deliver stable, low-latency performance for demanding applications.

Designed for true plug-and-play deployment, the UDB supports UniFi Auto-Link, making setup quick and effortless within UniFi ecosystems. It’s an excellent choice for extending connectivity between devices without running physical cables, especially in enterprise and SMB networks. If you’re looking to build or expand a reliable wireless infrastructure, explore our full range of Ubiquiti networking solutions to find the right fit for your setup.

MODEL	UDB
DIMENSIONS & WEIGHT	Dimensions: 130 x 55 x 34 mm (5.1 x 2.2 x 1.3″) Weight: 200 g (7.1 oz)
ENCLOSURE & MOUNT	Enclosure Material: Polycarbonate Mount Material: Polycarbonate Mounting Locations: Wall, table Mounting: Wall (Included) Button: (1) Factory-reset LEDs: System (4) Blue: signal (1) White/blue: indicator
POWER	Power Method: 100—240V AC, 0.45A Max., 50/60 Hz Max. Power Consumption: 25W (AC input) Max. Power Consumption (Excluding PoE output): 10W Supported Voltage Range: 100—240V AC
NETWORKING	Networking Interface: (1) GbE RJ45 port Management: WiFi
WIFI	WiFi Standard: WiFi 5 (802.11ac) Spatial Streams: 2 MIMO (5 GHz): 2 x 2 Channel Bandwidths: 20/40/80 MHz Max. Data Rate (5 GHz): 866.7 Mbps (BW80) Antenna Gain (5 GHz): Internal: 5 dBi External omni: 4 dBi, 360° x 30° Antennas: (1) Internal antenna (1) RP-SMA connector for external omni-antenna Max. TX Power (5 GHz): 21 dBm Supported Data Rates: 802.11ac (WiFi 5): 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps Wireless Security: WPA2 AES
OPERATING FREQUENCY	US/CA: U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 5150 – 5875 MHz
ENVIRONMENT	Ambient Operating Temperature: -10 to 40° C (14 to 104° F) Ambient Operating Humidity: 5 to 95% noncondensing
COMPLIANCE & CERTIFICATIONS	NDAA Compliant: ✓ Certifications: CE, FCC, IC, Anatel: 03885-25-08356
Manufacturers	UBIQUITI NETWORKS
