TP-Link TL-SG1008P

Name: TP-Link TL-SG1008P | 8-Port Gigabit PoE Switch | Spogmey
SKU: TPL-TL-SG1008P
Price: 80.00 USD
Availability: InStock

Original price was: $109.00.Current price is: $80.00.

Weight: 2.09 lbs
Dimensions: 11.02 × 8.78 × 2.68 in
Brand: Yealink
Switch Type: Unmanaged Switches
Number of Ports: 5-10
Main Port Speed: Gigabit
Uplink Ports: Gigabit RJ45
Layer Support: L2
PoE Support: Yes
PoE Budget: Low (30-70 W)
Redundant Power Supply: No
Shipping & Tax: Calculated at Checkout

5 in stock

Sold: 0

Available: 5

About TP-Link TL-SG1008P:

8× 10/100/1000 Mbps RJ45 ports.
4× PoE+ ports transfer data and power on the cables
Works with IEEE 802.3af/at compliant PDs
Plug and Play, no configuration and installation required
802.1p/DSCP QoS enable smooth latency-sensitive traffic
Supports PoE power up to 30 W for each PoE port
Supports PoE power up to 64 W for all PoE ports^*

Have A Question?

888.996.9609 Ask An Expert >

Industry Best Pricing
Quantity discounts available

Friendly Associates
Pre-sales product and solution advice

Expert Tech Support
Add-on tech support plans available

Super Fast Delivery
Same day shipping on most orders

The TP-Link TL-SG1008P provides 8 10/100/1000Mbps RJ45 ports, port 1 to port 4 of the switch support the 802.3af/at-compliant PoE standard with total PoE power budget of 64W*. The TL-SG1008P is an unmanaged switch with desktop/wall-mountable design, outstanding performance and quality, which is a great selection for expanding your network.

Interface	8× 10/100/1000 Mbps RJ45 Ports AUTO Negotiation AUTO MDI/MDIX
Network Media	•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity	Fanless
Physical Security Lock	Yes
External Power Supply	External power adapter (Output: 54VDC / 1.3A)
Packet Forwarding Rate	11.904 Mpps
PoE Ports (RJ45)	• Standard: 802.3 af/at compliant • PoE Ports: ports 1–4 • Power budget for all PoE ports: 64 W
Mac Address Table	4K
Jumbo Frame	16 KB
Switching Capacity	16 Gbps
Dimensions ( W x D x H )	6.7 × 3.9 × 1.1 in (171×98×27 mm)
Max Power Consumption	• 5.4 W (with no PD connected) • 75 W (with 64W PD connected)
Max Heat Dissipation	• 18.4 BTU/h (with no PD connected) • 225.8 BTU/h (with 64 W PD connected)
Transmission Method	Store-And-Forward
Advanced Functions	• Compatible With IEEE 802.3af/at Compliant PDs • IGMP Snooping • Mac Address Auto-Learning And Auto-Aging • IEEE802.3x Flow Control • 802.1p/DSCP QoS
Certification	CE, FCC, RoHS
Package Contents	• TL-SG1008P • Power Adapter • Installation Guide
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
Manufacturers	YEALINK
